Towmate Ram General Duty Standard Range

Trailer details

Details Key features Accessories Model specifications Download brochure

DEPENDABLE. VERSATILE. DURABLE.

The Ram General Duty Trailer. A universal solution for a variety of requirements.

Built from the ground up, the Ram general duty trailer is no pushover when it comes to hard work, sporting a tough galvanised steel frame and symbolising the durability and versatility you’ve come to expect from Towmate Trailers.

We’ve included some brand new innovations, that are unique to Towmate Trailers, including our unique hinged mesh sides, which are completely removable and provide easy access via the sides of the trailer.

The Ram General Duty Trailer. A universal solution for a variety of requirements.

Built Rugged. Built For You.

With a choice of three different lengths; 8, 10, or 12 foot, three different widths; 4, 5, or 6 foot, and a range of weight capacities available, there is a general purpose trailer for any requirement.

MODULAR CHASSIS

Our modular chassis design allows complete customisation to your needs with options that are available for add-on in the future.

SPARE WHEEL CARRIER

Mounted convieniently on the front headboard of the trailer. Lockable to increase security.

FULLY TYPE APPROVED

The full range of our Rhino Plant trailers are fully type approved with VCA accreditation.

LED Dual Voltage Lighting
Option of 50mm Locking Head or 40mm Eye Coupling
WheelSentry
Rear Propstands
Hinged Mesh Side Kit
Ladder Rack
Winch Options - Manual or Electric

Models

No models have been set up

Model:	Tyres:	Gross weight:	Payload:	Unladen weight:	Internal length:	Internal width:	Overall length:	Overall width:	Side height:	Loading height:
TGD084-15	185/70R13	1500kg	1068kg	432kg	2465mm	1180mm	3776mm	1820mm	340mm	395mm
TGD084-15FWR	185/70R13	1500kg	1010kg	490kg	2465mm	1180mm	3776mm	1820mm	340mm	395mm
TGD084-18	185/70R13	1800kg	1368kg	432kg	2465mm	1180mm	3776mm	1820mm	340mm	395mm
TGD084-18FWR	185/70R13	1800kg	1310kg	490kg	2465mm	1180mm	3776mm	1820mm	340mm	395mm
TGD084-27	185/70R13	2700kg	2210kg	490kg	2465mm	1180mm	3776mm	1820mm	340mm	395mm
TGD084-27FWR	185/70R13	2700kg	2152kg	548kg	2465mm	1180mm	3776mm	1820mm	340mm	395mm
TGD085-15	185/70R13	1500kg	1044kg	456kg	2465mm	1430mm	3776mm	2070mm	340mm	395mm
TGD085-15FWR	185/70R13	1500kg	980kg	520kg	2465mm	1430mm	3776mm	2070mm	340mm	395mm
TGD085-18	185/70R13	1800kg	1344kg	456kg	2465mm	1430mm	3776mm	2070mm	340mm	395mm
TGD085-18FWR	185/70R13	1800kg	1280kg	520kg	2465mm	1430mm	3776mm	2070mm	340mm	395mm
TGD085-27	185/70R13	2700kg	2186kg	514kg	2465mm	1430mm	3776mm	2070mm	340mm	395mm
TGD085-27FWR	185/70R13	2700kg	2122kg	578kg	2465mm	1430mm	3776mm	2070mm	340mm	395mm
TGD105-27	185/70R13	2700kg	22150kg	550kg	2965mm	1430mm	4273mm	2070mm	340mm	395mm
TGD105-27FWR	185/70R13	2700kg	2086kg	614kg	2965mm	1430mm	4273mm	2070mm	340mm	395mm
TGD105-35	185/70R13	3500kg	2890kg	610kg	2965mm	1430mm	4273mm	2070mm	340mm	395mm
TGD105-35FWR	185/70R13	3500kgs	2826kg	674kg	2965mm	1430mm	4273mm	2070mm	340mm	395mm
TGD106-27	185/70R13	2700kg	2126kg	574kg	2965mm	1730mm	4273mm	2370mm	340mm	395mm
TGD106-27FWR	185/70R13	2700kg	2053kg	647kg	2965mm	1730mm	4273mm	2370mm	340mm	395mm
TGD106-35	185/70R13	3500kg	2866kg	634kg	2965mm	1730mm	4273mm	2370mm	340mm	395mm
TGD106-35FWR	185/70R13	3500kg	2793kg	707kg	2965mm	1730mm	4273mm	2370mm	340mm	395mm
TGD125-27	185/70R13	2700kg	2115kg	585kg	3580mm	1430mm	4886mm	2070mm	340mm	395mm
TGD125-27FWR	185/70R13	2700kg	2051kg	649kg	3580mm	1430mm	4886mm	2070mm	340mm	395mm
TGD125-35	185/70R13	3500kg	2829kg	645kg	3580mm	1430mm	4886mm	2070mm	340mm	395mm
TGD125-35FWR	185/70R13	3500kg	2791kg	709kg	3580mm	1430mm	4886mm	2070mm	340mm	395mm
TGD126-27	185/70R13	2700kg	2089kh	611kg	3580mm	1730mm	4886mm	2370mm	340mm	395mm
TGD126-27FWR	185/70R13	2700kg	2016kg	684kg	3580mm	1730mm	4886mm	2370mm	340mm	395mm
TGD126-35	185/70R13	3500kg	2829kg	671kg	3580mm	1730mm	4886mm	2370mm	340mm	395mm
TGD126-35FWR	185/70R13	3500kg	2756kg	744kg	3580mm	1730mm	4886mm	2370mm	340mm	395mm
